Naim NAC 332 — Preamplificador

ESPECIFICACIONES

Ficha técnica

Crosstalk - Line: Line: 90dB at 1kHz, volume at 0dB / (Line: 70dB at 20kHz, volume at 0dB) · Frequency response - line: Line: 3Hz to 40kHz -3dB · Distortion - Line: Line: 0.003% @2.2V input volume at 0dB, 1kHz / (Line: 0.018% @2.2V input volume at 0dB, 20kHz). / Dominated by 2nd harmonic and noise · Tipo de producto: Preamplifier · Ganancia analógica: Preamplifier at max volume: 15.5dB · Entradas analógicas: 1 x 8-pin DIN (47kΩ, 2.2V typical, 9.5Vrms Max) / 2 x 5-pin DIN (47kΩ, 2.2V typical, 9.5Vrms Max) / 3 x RCA par (47kΩ, 2.2V typical, 9.5Vrms Max) / 2 x XLR balanceado par (100kΩ, 2.2V typical, 9.5V max) / 8-pin DIN compatibles con 5-pin DIN / 8-pin DIN has +/-18V (for compatible external phono stages e.g. NVC TT) · Salidas analógicas: 1 x XLR par (balanceado 10Vrms max) / 1 x RCA par (10Vrms max) / 1 x 6.35mm headphone jack (1.5W into 16Ω) · Salidas para audífonos: 1 x jack 6,35 mm · USB ports: 1 x USB port (for updates) · Phono inputs (line): 8 pin DIN has +/-18V for compatible external phono stages such as NVC TT · Control por app: Focal & Naim App · Control system: Zigbee RF bi-directive Control remoto · Actualizaciones: 1 x USB socket (for update) · Control de usuario: Eight buttons for quick access to standby, mute and inputs. / Volume control. · Consumo en uso normal: 20 W · Cable de alimentación: PowerLine Lite · Alimentación de red: 100V, 115V or 230V, 50/60Hz · Profundidad: 31.75 cm / 12.5 in · Altura: 9.15 cm / 3.62 in · Ancho: 43.2 cm / 17 in · Peso: 11 kg / 24
